Mining Rock Drill Button Bits Taper 11

  • Product Item：1270279031
  • Model Number:Q0907
  • Type:mining drill bit
  • Material:Tungsten Carbide
  • Use:Mining Rock Drill Button Bits
  • Category：Tapered Drill Bit

    • Sent E-mail Inquiry

    Description

    Mining rock drill button bits Taper 11


    Diameter No*Buttons diameter mm Button angle Air holes Weight(Kg) Part No
    mm inch Guuge Front
    Drill bits for CIR90A hammers
    90 31/2 6*14 2*13+2*12 45 2 3.6 CIR90A-90BVC6
    100 4 6*14 3*13+2*12 45 3 4 CIR90A-100BVC6
    110 41/3 6*14 3*13+3*12 45 3 4.7 CIR90A-110BVC6
    120 43/4 6*14 3*13+4*12 45 3 5.2 CIR90A-120BVC6
    130 51/8 6*14 3*14+4*12 45 3 6.2 CIR90A-130BVC6
    140 51/2 9*14 3*14+5*12 45 3 7.8 CIR90A-1400BVC6
    150 6 3*14 2*13+5*12 45 3 8.4 CIR90A-150BVC6


    -Cemented Carbide Drill Bit.jpg
